Mastering Local Persistent Volumes on Kubernetes: A Practical Guide

Kubernetes

✍ Hands-On Guide

📅 Published on January 24, 2024

Introduction

Kubernetes is an extremely powerful platform that allows you to easily schedule hundreds of workloads across dozens of nodes. In many cases, a large portion of these containers can do their job without ever having to think about storage or disk space. Sooner or later, however, you'll want to deploy an application that requires persistent storage. Without any specific configuration, any files written to disk are lost forever when a Pod gets deleted or evicted. Luckily, Kubernetes provides plenty of options to resolve this issue. While the bulk of these solutions are specific to the cloud you're using (e.g. Microsoft Azure, Google Cloud Platform or Amazon Web Services), some cloud-agnostic alternatives exist. The simplest choice is to use Local Persistent Volumes, which is built into Kubernetes itself and has been promoted to General Availability in version 1.14.

Prerequisites and Assumptions

This guide builds on top of Installing a Kubernetes Cluster on Ubuntu with kubeadm. It assumes you have a working Kubernetes cluster on which Pods can be deployed and started.

Persistent Volumes

A Persistent Volume is a definition of storage that is available in the cluster and which has been provisioned either manually by an administrator (static) or automatically by a Storage Class provisioner (dynamic). It captures the details of a piece of storage backed by a specific storage technology such as NFS, local storage or a cloud-provider-specific storage system. The PersistentVolume resource typically includes the storage class, capacity and supported access modes (e.g. read-write by a single node). In turn, a Storage Class is the description of a specific kind of storage that can be made available to the cluster, such as regular HDD storage, high-speed SSD storage or Azure File Storage.

Persistent Volumes can be provisioned either statically or dynamically. Static provisioning simply means the cluster administrator has to perform a manual action to create that Persistent Volume. Consequently, the administrator is also responsible for creating, maintaining and cleaning up the underlying storage, such as (a directory on) a physical HDD. This type of provisioning is more common with "vanilla" clusters installed from scratch, such as on-premise Kubernetes installations or clusters used for development and testing purposes. The cluster administrator has total control over what kind of storage they make available to the cluster.

Dynamic provisioning means that Persistent Volumes get created on-demand by an automated system whenever an application calls for it. In this case, the application is leading in what type and size of storage gets provisioned. Cloud providers typically include this type of provisioning in their offering.

Persistent Volume Claims

A Persistent Volume (PV) is an abstraction layer that decouples persistent storage from individual Pods. Consequently, it has a completely separate lifecycle, meaning your Persistent Volume will stay in place when your Pod gets deleted. The bridge between a Pod and a Persistent Volume is made through a Persistent Volume Claim (PVC).

As the name implies, a PVC attempts to claim a certain type and amount of storage by defining the desired storage class, requested capacity and access mode. PVCs typically only get removed whenever the entire application gets removed from the cluster. What happens as a result depends on the way the Persistent Volume was defined. This phase is called reclaiming the Persistent Volume.

With most cloud providers, Persistent Volumes are automatically deleted (reclaimed) whenever the Persistent Volume Claim gets removed. Therefore, deleting the Persistent Volume Claim has a direct effect on the underlying storage (e.g. the virtual hard disk will be removed). This makes sense, because the PV gets provisioned the same way: it is created on-demand whenever an application requires it through the definition of a PVC.

With static provisioning, the cluster administrator is responsible for the maintenance and cleanup of Persistent Volumes. Kubernetes itself will not delete any files from the underlying storage and will keep the Persistent Volume around in the Released state. It's then up to you as the cluster administrator to manually make that storage available again. If you want to reuse it for another application, you need to remove all files from the underlying storage and recreate the Persistent Volume in Kubernetes.

Local Persistent Volumes

Out of the box, Kubernetes provides support for Local Persistent Volumes. These are Persistent Volumes backed by a node's local storage (i.e., the physical disk). While you can define your own Storage Class to tweak the binding behavior and make it more intelligent, it isn't strictly required. As long as the PV and the PVC use the same Storage Class name, Kubernetes will be able to bind that claim. Defining a Local Persistent Volume is fairly simple and can be done as follows.

apiVersion: v1
kind: PersistentVolume
metadata:
  name: hdd-chunk-50g-1
  labels:
    storage-type: hdd
spec:
  capacity:
    storage: 50Gi
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: local-storage
  local:
    path: /k8s-data-hdd/chunk-50g-1
  nodeAffinity:
    required:
      nodeSelectorTerms:
        - matchExpressions:
            - key: kubernetes.io/hostname
              operator: In
              values:
                - pop-os

In the above YAML snippet, we define the PersistentVolume resource with a capacity of 50 GiB. Due to its very nature, this kind of Persistent Volume is bound to a predefined path on the physical disk of a specific node in the cluster. In this case, that's the node with hostname pop-os.

It's important to note that Kubernetes does not reserve any disk space whatsoever. As a cluster administrator, you need to make sure all Persistent Volumes are defined in line with the available storage. In other words, you need to ensure that sufficient disk space is available and files can be written to the configured path. Even when the total capacity of the HDD is only 100 GiB, Kubernetes won't stop you from defining several 200 GiB Persistent Volumes.

The following snippet shows an example definition of a Persistent Volume Claim. The storage class name and label selector tells Kubernetes what to look for when trying to bind this PVC to one of the available PVs. As long as this PVC requests less or equal storage capacity than defined in the PV, it can be bound to it. Note that PersistentVolume exists as a cluster resource, while PersistentVolumeClaim resides within a namespace.

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: your-data
  namespace: your-application
spec:
  storageClassName: local-storage
  selector:
    matchLabels:
      storage-type: hdd
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 50Gi

Example: Deploying a Database

Now that we went over the concepts, it's time to put it all into practice and walk through an example of deploying a PostgreSQL database. Starting off, we need to have a location for PostgreSQL to put its files. We'll create a directory and change the owning user and group to ID 2001, so we can work with a predictable UID and GID inside the container and avoid permission issues.

sudo mkdir -p /k8s-data/hdd-chunk-10g-1
sudo chown 2001 /k8s-data/hdd-chunk-10g-1/
sudo chgrp 2001 /k8s-data/hdd-chunk-10g-1/

Next, we define the Persistent Volume according to the created directory and intended disk space usage. As mentioned before, we can't explicitly reserve any capacity through this configuration, so the listed storage capacity is merely indicative and serves as a criteria for binding a Persistent Volume Claim (the requested capacity must be smaller or equal to the storage capacity of the Persistent Volume).

apiVersion: v1
kind: PersistentVolume
metadata:
  name: hdd-chunk-10g-1
  labels:
    storage-type: hdd
spec:
  capacity:
    storage: 10Gi
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: local-storage
  local:
    path: /k8s-data/hdd-chunk-10g-1
  nodeAffinity:
    required:
      nodeSelectorTerms:
        - matchExpressions:
            - key: kubernetes.io/hostname
              operator: In
              values:
                - jelle-virtualbox

Because Persistent Volume Claims are scoped to a namespace, we have to create one before we can define the PersistentVolumeClaim resource.

kubectl create namespace postgresql
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: postgresql-data
  namespace: postgresql
spec:
  storageClassName: local-storage
  selector:
    matchLabels:
      storage-type: hdd
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Gi

These steps are all that's required for the volume part. At this point, we can deploy our application and start using the storage we just claimed. I'll apply some best practices here and create a randomized secret for the database's admin user. Then we can deploy the PostgreSQL instance itself, which we'll do through a Deployment with exactly 1 replica (chosen for simplicity, alternatively a Stateful Set could be used). I choose not to mount the default service account token, because the Pod simply doesn't need it and because it makes the setup slightly more secure. I also run the container with user and group 2001, so that it matches the UID and GID of the assigned directory. The container would run as root (UID and GID 0) by default, which poses a risk because root inside the container is also root on the host. This is especially problematic if the container has direct access to the host's file system.

kubectl -n postgresql create secret generic postgresql-admin \
    --from-literal=username=postgres \
    --from-literal=password=$(head /dev/urandom | tr -dc A-Za-z0-9 | head -c 32)
apiVersion: apps/v1
kind: Deployment
metadata:
  name: postgresql
  namespace: postgresql
spec:
  selector:
    matchLabels:
      app: postgresql
  strategy:
    type: Recreate
  replicas: 1
  template:
    metadata:
      labels:
        app: postgresql
    spec:
      automountServiceAccountToken: false
      containers:
        - name: postgresql
          image: postgres:12.4
          env:
            - name: POSTGRES_USER
              valueFrom:
                secretKeyRef:
                  name: postgresql-admin
                  key: username
            - name: POSTGRES_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: postgresql-admin
                  key: password
          ports:
            - name: postgres
              containerPort: 5432
          volumeMounts:
            - name: postgresql-data
              mountPath: /var/lib/postgresql/data
          resources:
            requests:
              memory: 250Mi
            limits:
              memory: 500Mi
      volumes:
        - name: postgresql-data
          persistentVolumeClaim:
            claimName: postgresql-data
      securityContext:
        runAsUser: 2001
        runAsGroup: 2001

We're all set now! PostgreSQL should have successfully started and be initialized, as indicated by the following logs.

PostgreSQL init process complete; ready for start up.

2024-01-14 21:29:31.126 UTC [1] LOG:  starting PostgreSQL 12.4 (Debian 12.4-1.pgdg100+1) on x86_64-pc-linux-gnu, compiled by gcc (Debian 8.3.0-6) 8.3.0, 64-bit
2024-01-14 21:29:31.127 UTC [1] LOG:  listening on IPv4 address "0.0.0.0", port 5432
2024-01-14 21:29:31.127 UTC [1] LOG:  listening on IPv6 address "::", port 5432
2024-01-14 21:29:31.137 UTC [1] LOG:  listening on Unix socket "/var/run/postgresql/.s.PGSQL.5432"
2024-01-14 21:29:31.171 UTC [49] LOG:  database system was shut down at 2024-01-14 21:29:31 UTC
2024-01-14 21:29:31.190 UTC [1] LOG:  database system is ready to accept connections

There is one big caveat to look out for when using Local Persistent Volumes. This specific storage configuration does not have any monitoring, restrictions or quota in place whatsoever. This means there is no actual limit on how much disk space the Pod can use. Nothing stops the container from creating a 12 GiB file inside the 10 GiB local volume, as illustrated in the following example.

$ kubectl -n postgresql exec -it postgresql-85bc4b5f4c-fp4mh -- /bin/bash
I have no name!@postgresql-85bc4b5f4c-fp4mh:/$ dd bs=4096 count=3145728 if=/dev/zero of=/var/lib/postgresql/data/large-file.dat
3145728+0 records in
3145728+0 records out
12884901888 bytes (13 GB, 12 GiB) copied, 42.0163 s, 307 MB/s
$ sudo du -sh /k8s-data/hdd-chunk-10g-1/
13G     /k8s-data/hdd-chunk-10g-1/

The absence of a hard limit on these volumes might not be a big problem for small clusters, but for clusters running hundreds of workloads this could pose a real risk. Once one container starts using more space than requested, it can disrupt other Pods and the node can experience disk pressure, leading to downgraded performance and Pod evictions. Fortunately, there is a way to work around this problem and mitigate this risk.

File System in a File

Linux gives us the wonderful ability to create a file system inside a plain file. Once mounted, this file is treated as a full-fledged file system that behaves just like a formatted disk partition. Just like with a disk partition, it has a predefined size that cannot be altered from inside the file system. It's a simple trick you can use to put a hard limit on a directory backing a Persistent Volume. Let's revise the steps needed for this kind of configuration. Because we will start off by removing the previously created "chunk" directory, I scale down the PostgreSQL deployment to 0 replicas so no Pods try to access the disk anymore.

kubectl -n postgresql scale deployment postgresql --replicas 0
sudo rm -rf /k8s-data/hdd-chunk-10g-1/

The next step is creating the file in which we will create the file system. With the following command, we can create a 10 GiB file that is filled with null bytes (it might take a minute).

jelle@jelle-VirtualBox:/k8s-data/fs$ sudo dd if=/dev/zero of=/k8s-data/fs/hdd-chunk-10g-1 bs=4096 count=2621440
2621440+0 records in
2621440+0 records out
10737418240 bytes (11 GB, 10 GiB) copied, 24,7031 s, 435 MB/s

Once the file itself has been created, we can format it with the desired file system. The most logical choice is ext4, which is the same file system as the one used by the node.

jelle@jelle-VirtualBox:/k8s-data/fs$ sudo mkfs.ext4 /k8s-data/fs/hdd-chunk-10g-1
mke2fs 1.46.5 (30-Dec-2021)
Discarding device blocks: done
Creating filesystem with 2621440 4k blocks and 655360 inodes
Filesystem UUID: a987be1d-cf07-4b50-bb4a-62ef1356f667
Superblock backups stored on blocks:
        32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632

Allocating group tables: done
Writing inode tables: done
Creating journal (16384 blocks): done
Writing superblocks and filesystem accounting information: done

In order to actually be able to use this file, we need to mount it to a location on disk. After running the commands below, you can use ls -lha /k8s-data/hdd-chunk-10g-1 analogous to any other disk partition.

sudo mkdir /k8s-data/hdd-chunk-10g-1
sudo mount -o loop,rw /k8s-data/fs/hdd-chunk-10g-1 /k8s-data/hdd-chunk-10g-1

Keep in mind that you need to configure this mount in /etc/fstab to preserve it throughout reboots of the host.

$ cat /etc/fstab
...
/k8s-data/fs/hdd-chunk-10g-1 /k8s-data/hdd-chunk-10g-1 ext4 loop,rw 0 0

After mounting this new file system, we should create a subdirectory in which the actual data will be stored. There are 2 reasons for doing this. The first reason is that some applications (including PostgreSQL) refuse to start when they detect a lost+found directory. The second reason is that using a subdirectory is more secure because it allows you to set permissions selectively (e.g. change the owning user) without having to do so for the entire file system. For simplicity, I'll call this directory data.

sudo mkdir /k8s-data/hdd-chunk-10g-1/data
sudo chown 2001 /k8s-data/hdd-chunk-10g-1/data
sudo chgrp 2001 /k8s-data/hdd-chunk-10g-1/data

Now, there is only one remaining step. We need to change the Deployment definition so that Kubernetes mounts the data directory in the PostgreSQL container, instead of the file system root. More specifically, we need to define a subPath for the mounted postgresql-data volume, which is the directory we just created.

volumeMounts:
  - name: postgresql-data
    mountPath: /var/lib/postgresql/data
    subPath: data

All done! Apply the Deployment again with kubectl apply and all PostgreSQL data files should be contained within this data directory.

What would happen now if PostgreSQL tried to create a file with a larger size than this in-file file system?

jelle@jelle-VirtualBox:/k8s-data/fs$ kubectl -n postgresql exec -it postgresql-8569b9b767-6d49h -- /bin/bash
I have no name!@postgresql-8569b9b767-6d49h:/$ dd bs=4096 count=3145728 if=/dev/zero of=/var/lib/postgresql/data/large-file.dat
dd: error writing '/var/lib/postgresql/data/large-file.dat': No space left on device
2409364+0 records in
2409363+0 records out
9868750848 bytes (9.9 GB, 9.2 GiB) copied, 45.4573 s, 217 MB/s

The application has no way anymore to step outside the predefined bounds. Any attempt to do so results in an error.

Summary, Benefits and Drawbacks

It only takes about 25 lines of YAML to define a local Persistent Volume and merely 15 to claim it for use. This makes local storage an interesting choice if you don't mind performing a few manual actions. It also proves that storage within a Kubernetes cluster doesn't always have to be as complicated as some make it out to be. That being said, this is not a one-size-fits-all solution and comes with its fair share of drawbacks. Let's have a look at the considerations for Local Persistent Volumes so that you can make a well-informed decision about whether this is worth trying out for your specific use case.

Benefits

Drawbacks
